Trek Rail+ 9.7 Gen 5 eBike - 2025

0.0|reviewsID:

3049442

$8,249.99$8,249.990% off
Color:* Requires selection
  • Frame Size* Requires selection
  • Wheel Size* Requires selection
Al's return policy

Trek Rail+ 9.7 Gen 5 eBike - 2025

The 2025 Trek Rail+ 9.7 Gen 5 eBike is a full suspension e-bike for taking on mountainous trails. Suspension for cushioning bumpy terrain and a Bosch Performance CX system to deliver lots of boost on the uphills and beyond, allowing for longer rides and extra laps. The carbon frame construction is lightweight, dampens even more of the harsh terrain, making for a smooth, quick ride.

Features

  • Rail+ delivers adventure with plenty of travel and power for getting after epic rides that take you peak to peak or chasing endless enduro laps
  • The powerful Bosch Performance CX system goes full gas up steep climbs and keeps you cool for the descents
  • You can tweak your geometry and suspension leverage rate for how you ride, and add in adjustable angle headset cups (sold separately) for even more adjustability
  • The massive 800Wh RIB 2.0 battery supports you for big miles and can be easily removed for travel or storage
  • It's compatible with the Bosch PowerMore booster battery for going even further on epic adventures
  • A 160mm RockShox Domain RC fork with DebonAir spring, Motion Control damper, and lockout, and RockShox Deluxe Select+ rear shock
  • Weight - 52.32 lbs

Components

  • Frame - OCLV Mountain Carbon, Removable Integrated Battery (RIB 2.0), tapered head tube, guided internal routing, Motor Armor, angle-adjust headset, Mino Link adjustable geometry, adjustable leverage rate, 34.9mm seat tube, ABP, UDH Boost148, 12 mm thru axle, 160 mm travel
  • Fork - RockShox ZEB Select, DebonAir spring, Charger RC damper, tapered steerer, 44mm offset, Boost110, Maxle Stealth, 160mm travel
  • Shock - RockShox Super Deluxe Select+ RT, 205mm x 65mm
  • Wheel Front - Bontrager Line Comp 30, Tubeless Ready, 6-bolt, Boost110, 15mm thru axle, 29''
  • Wheel Rear - Bontrager Line Comp 30, High Strength 6000 Series Aluminum rim, Tubeless Ready, Rapid Drive 108, 6-bolt, Shimano MicroSpline freehub, Boost148, 12mm thru axle, 27.5''
  • Skewer Rear - Bontrager Switch thru axle, removable lever
  • Tire - Bontrager Brevard Pro XR, Tubeless Ready, dual compound, aramid bead, 60 tpi, 29x2.50''
  • Charger - Bosch standard 4A, 110V, smart system
  • Controller - Bosch System Controller BRC3100, smart system
  • Motor - Bosch Performance Line CX, 20 mph / 32 km/h max assist
  • Shifter - Shimano SLX M7100, 12 speed
  • Rear Derailleur - Shimano XT M8100, long cage
  • Crank Arm - E*thirteen E*spec Plus, 160mm length
  • Cassette - Shimano SLX M7100, 10-51T, 12 speed
  • Chain - Shimano SLX M7100, 12 speed
  • Saddle - Bontrager Verse P3, chromoly rails
  • Seatpost - Bontrager Line Dropper, 170mm travel, MaxFlow, internal routing, 34.9mm, 450mm length
  • Handlebar - Bontrager Line, alloy, 35mm, 27.5mm rise, 780mm width
  • Grips - Bontrager XR Trail Comp, nylon lock-on
  • Stem - Bontrager Elite, 35mm, 0 degree, 45mm length
  • Headset - Integrated cartridge bearing, 1-1/8'' top, 1.5'' bottom, angle adjust cup compatible
  • Brake - SRAM DB 8 4-piston hydraulic disc
  • Brake Rotor - SRAM CenterLine, 6-bolt, round edge, 200mm
