Rail+ 5 Gen 5 eBike - 2026

0.0|reviews
ID:

3049447

$6,099.99$6,099.990% off
Color:Select Color* Requires selection
  • Frame Size* Requires selection
  • Wheel Size* Requires selection
Warehouse Liquidation UATC

Description

Rail+ 5 is an alloy enduro e-bike that delivers huge value for big adventures. It comes equipped with a Bosch Performance CX drive system with full power for crushing laps and big climbs while its massive battery takes you the distance. 160mm of front and rear travel make Rail+ super capable in the rough and rowdy, and adjustable geometry lets you customize it for how and where you ride.

  • Rail+ delivers adventure with plenty of travel and power for getting after epic rides that take you peak to peak or chasing endless enduro laps
  • The powerful Bosch Performance CX system goes full gas up steep climbs and keeps you cool for the descents
  • You can tweak your geometry and suspension leverage rate for how you ride, and add in adjustable angle headset cups (sold separately) for even more adjustability
  • The massive 800Wh RIB 2.0 battery supports you for big miles and can be easily removed for travel or storage
  • It's compatible with the Bosch PowerMore booster battery for going even further on epic adventures
  • Equipped with a 160mm RockShox 35 Gold RL fork with DebonAir spring, Motion Control damper with lockout, and a RockShox Deluxe Select+ RT shock
  • Weight - 55.74 lbs

Tech Specs

  • E-Bike
    • Motor
      Bosch Performance Line CX, 20 mph / 32 km/h max assist
    • Controller
      Bosch System Controller BRC3100, smart system
    • Charger
      Bosch standard 2A, 110V, smart system
  • Frameset
    • Frame
      Alpha Platinum Aluminum, Removable Integrated Battery (RIB 2.0), tapered head tube, guided internal routing, Motor Armor, angle-adjust headset, Mino Link adjustable geometry, adjustable leverage rate, 34.9mm seat tube, ABP, UDH, Boost148, 12 mm thru axle, 160 mm travel
  • Suspension
    • Fork
      RockShox Psylo Gold RC, DebonAir spring, Isolator RC damper, tapered steerer, 44mm offset, Boost 110, 15mm Maxle Stealth, 160mm travel
    • Shock
      RockShox Deluxe Select+ RT, 205mm x 65mm
  • Brakes
    • Brake Rotor
      Shimano RT66, 6-bolt, 203mm
    • Brake
      Shimano 4-piston hydraulic disc, MT4100 lever, MT420 caliper
  • Drivetrain
    • Crank Arm
      E*thirteen E*spec Plus, 160mm length
    • Rear Derailleur
      Shimano Deore M6100, long cage
    • Cassette
      Shimano Deore M6100, 10-51, 12 speed
    • Chain
      Shimano Deore M6100, 12 speed
    • Shifter
      Shimano Deore M6100, 12 speed
  • Wheels & Tires
    • Hub Front
      Bontrager sealed bearing, alloy axle, 6-bolt, Boost110, 15mm thru axle
    • Hub Rear
      Bontrager alloy, sealed bearing, 6-bolt, Shimano MicroSpline freehub, Boost148, 12mm thru axle
    • Skewer Rear
      Bontrager Switch thru axle, removable lever
    • Tires
      Bontrager Gunnison Elite XR, Tubeless Ready, wire bead, 60 tpi, 27.5x2.40''
    • Tires
      Bontrager Gunnison Elite XR, Tubeless Ready, wire bead, 60 tpi, 29x2.40''
    • Rim Strip
      Bontrager TLR
    • Rim
      Bontrager Line TLR 30, Tubeless Ready, 32-hole, Presta valve
  • Cockpit
    • Seatpost (S)
      TranzX JD-YSI34, 100mm travel, internal routing, 34.9mm
    • Seatpost (M, L, XL)
      TranzX JD-YSI34, 170mm travel, internal routing, 34.9mm
    • Stem
      Bontrager Comp, 31.8mm, Blendr compatible, 7 degree, 50mm length
    • Handlebar
      Bontrager alloy, 31.8mm, 15mm rise, 750mm width
    • Grips
      Bontrager XR Trail Comp, nylon lock-on
    • Saddle
      Bontrager Verse P3, steel rails
    • Headset
      Integrated cartridge bearing, 1-1/8'' top, 1.5'' bottom, angle adjust cup compatible
