Trek

Marlin 5 Gen 3 Bike - 2026

0.0|reviews
ID:

3127708

$849.99$849.990% off
Color:Select Color* Requires selection
  • Frame Size* Requires selection
  • Wheel Size* Requires selection
Al's return policyPre Black Friday Sale
  • Marlin 5 is a trail-worthy daily rider that's perfectly suited for everyday adventures, on and off the trail. It features a trail-savvy frame with a suspension fork, 9-speed Shimano CUES shifting, and mounts for a rack and kickstand that make it an ideal choice for trail riders or anyone looking for a comfortable, stable commuter with the ruggedness of a real mountain bike

Tech Specs

  • Frameset
    • Frame
      (Size XS) Alpha Silver Aluminum, curved top tube, internal derailleur & dropper post routing, rack and kickstand mount, 135x5mm ThruSkew
    • Frame
      (Size S , M , ML , L , XL , XXL) Alpha Silver Aluminum, internal derailleur & dropper post routing, rack and kickstand mount, 135x5mm ThruSkew
  • Suspension
    • Fork
      (Size XS) SR Suntour XCT 30, coil spring, preload, hydraulic lockout, 42 mm offset for 27.5'' wheel, 100 mm QR, 80 mm travel
    • Fork
      (Size S) SR Suntour XCT 30, coil spring, preload, hydraulic lockout, 42 mm offset for 27.5'' wheel, 100 mm QR, 100 mm travel
    • Fork
      (Size M , ML , L , XL , XXL) SR Suntour XCT 30, coil spring, preload, hydraulic lockout, 42 mm offset for 29'' wheel, 100 mm QR, 100 mm travel
  • Brakes
    • Brake Set
      Shimano MT200 hydraulic disc
    • Brake Rotor
      (Size XS , S , M , ML , L , XL , XXL) Shimano RT26, 6-bolt, 160mm
    • Brake Rotor
      (Size M , ML , L , XL , XXL) Shimano RT26, 6-bolt, 180mm
    • Brake
      Shimano MT200 hydraulic disc
  • Drivetrain
    • Rear Derailleur
      Shimano CUES U4000
    • Cassette
      Shimano LINKGLIDE LG300, 11-46, 9 speed
    • Chain
      Shimano LG500, 9/10/11 speed
    • Pedal
      VP-536 nylon platform
    • Shifter
      Shimano U4000, 9 speed
    • Crank
      (Size L , XL , XXL) Shimano CUES U4001, 32T, 52mm chainline, 175mm length
    • Bottom Bracket
      Shimano, 73mm, threaded cartridge, 122.5mm spindle
  • Wheels & Tires
    • Hub Front
      Formula DC-20, alloy, 6-bolt, 100x5mm
    • Skewer Front
      Trek Thru-Skew
    • Hub Rear
      Formula DC-22, alloy, 6-bolt, Shimano 8/9/10 freehub, 135x5mm
    • Skewer Rear
      173x5mm QR
    • Tire
      (Size XS, S) Bontrager Montrose Comp, wire bead, 30 tpi, 27.5x2.4''
    • Tire
      (Size M , ML , L , XL , XXL) Bontrager Montrose Comp, wire bead, 30 tpi, 29x2.4''
    • Rim
      Bontrager Connection, double-wall, 32-hole, 20mm width, schrader valve
    • Spokes
      14g stainless steel, black
  • Cockpit
    • Stem
      (Size XS, S) Bontrager Comp, 31.8mm, 7 degree, 35mm length
    • Stem
      (Size M , ML , L) Bontrager Comp, 31.8mm, Blendr compatible, 7 degree, 50mm length
    • Stem
      (Size XL) Bontrager Comp, 31.8mm, Blendr compatible, 7 degree, 60mm length
    • Stem
      (Size XXL) Bontrager Comp, 31.8mm, Blendr compatible, 7 degree, 70mm length
    • Handlebar
      (Size XS) Bontrager alloy, 31.8mm, 5mm rise, 690mm width
    • Handlebar
      (Size S) Bontrager alloy, 31.8mm, 15mm rise, 720mm width
    • Handlebar
      (Size M , ML , L , XL , XXL) Bontrager alloy, 31.8mm, 15mm rise, 750mm width
    • Grips
      Trek Line Comp, nylon lock-on
    • Saddle
      Bontrager Verse Short, stainless steel rails
    • Seatpost
      (Size XS , S , M) Bontrager alloy, 31.6mm, 12mm offset, 330mm length
    • Seatpost
      (Size ML , L , XL , XXL) Bontrager alloy, 31.6mm, 12mm offset, 400mm length
    • Headset
      Semi-integrated, 1-1/8''
  • Weight
    • Weight
      33.29 lbs
